BAGEL Digifav B2 DS – duplex laminator
Automatic duplex laminator: both sides in one pass, speeds up to approximately 25 m/min and optional SLEEKpro decorative finishing.
BAGEL Digifav B2 DS
Digifav B2 DS laminates both sides in one pass, reducing handling between production stages. Its oil-heated rollers support stable processing in simplex and duplex modes. Optional SLEEKpro finishing adds decorative effects for suitable print applications.
Technical specifications
| Speed | Up to approximately 25 m/min |
|---|---|
| Sheet size | Approximately 218 × 218–528 × 749 mm |
| Paper weight | 120–400 g/m², application-dependent |
| Film thickness | Approximately 25–51 µm |
| Upper / lower roll diameter | Up to approximately 533 / 362 mm |
| Stack height | Approximately 600 mm |
| Feeder capacity | Approximately 200 kg |
| Feeding | Pneumatic air suction; four front stops |
| Separation | Bursting with microperforation |
| Options | Jogger, pallet stacker, SLEEKpro module |
Performance depends on application, material and film. Options are additional equipment. Contact Graphotrade to select a setup for your applications.
