FENGCHI FZ-1450 Automatic Flip-Flop Stacker
Servo-controlled flip-flop stacker for counting, turning and forming neat piles of laminated sheets after a flute laminator.
The FENGCHI FZ-1450 automates sheet receiving after flute lamination and reduces manual handling. It can alternate stack orientation, count sheets and build aligned piles for the next production stage.
Key data: maximum sheet size 1450 × 1450 mm; minimum sheet size 500 × 380 mm; speed up to 15,000 sheets/hour; installed power approx. 12 kW; 380 V three-phase supply; weight approx. 3,800 kg; dimensions approx. 6,955 × 2,432 × 2,892 mm.
Full-servo control, touchscreen presets and one-key front/back stacking support consistent piles and a smoother laminating line. Integration requirements are confirmed against the upstream machine and sheet specification.
