KQ TS-1450U2 U-Shaped Tape Application Platform

KQ TS-1450U2 is an automatic U-shaped tape application platform for corrugated boxes. It combines friction feeding, sheet correction, non-contact cutting, HMI recipe management and automatic receiving.

TECHNICAL SPECIFICATIONS

• Applicator heads: 1–4

• Tape width: 5–35 / 10–60 / 20–80 mm

• Minimum sheet size: 300 × 300 mm

• Maximum sheet size: 1100 × 1450 mm

• Maximum speed: 120 m/min

• Application accuracy: ±2 mm

• Machine weight: 1820 kg

• Footprint: 5600 × 3900 mm

• Power supply: 50/60 Hz, AC 380 V

• Feeder motor: 1.5 kW

• Alignment motor: 0.75 kW

• Applicator section: 2.2 kW

• Delivery: 0.4 + 0.75 kW

• Total power: 5.8 kW
